Crack phase field of a turbine blade
Crack phase field of a turbine blade
Simulation of the crack evolution in a notched turbine blade using the phase field method. The blade geometry was provided by DLR Institute of Propulsion Technology. Visualization with Paraview.
Credit: DLR (CC BY-NC-ND 3.0)
