Three dimensional map
Three dimensional map
DLR's ALLFlight (Assisted Low Level Flight and Landing on Unprepared Landing Sites) research project involves the development of a system that generates a digital map for the cockpit, and helps the pilots in difficult situations - up to a fully automated landing. A total of four sensors are used in the creation of three-dimensional digital environment maps: TV camera, infrared camera, laser and radar. Once the data is combined, the pilot will only see a picture of the environment. On the top right is the environmental image obtained with the TV camera. The 3D image is visible on the left.
